SL-PRB02-x500

SL-PRB02, Wideband very low cost passibe RF probe with SMA 3.5mm connector, 3GHz+

Passive RF probe with 3GHz+ bandwidth, Attenuation factor set by discrete SMD resistor.

Probe usable for engineering and debug. The probe parts can be adapted by engineers at need

The probe is mainly dedicated to be used with a 50ohm wideband oscilloscopes

Default shipped series resistor option = 453Ohm

Use scope calibration setup to tune attenuation factor.

Applications: Perfect for Power supply very large bandwidth measurement and EMI conductive noise measurement

shipped with

• 2 units pogo test pin spring mount
• 1 double face silicon tape
